Wenzel – Coordinate Measure Machine (CMM)

  • CMM Inspection System
  • 80” x 120” x 60”
  • 5 Ton Work Piece with Overhead Crane
  • Accuracy over entire surface (0.00025” – 0.0005”)
  • Automated Video Measuring System
  • 24″x18″x6″
  • XY Accuracy E2 = (7+L/30) µm
  • Z Accuracy E2 = (5.0+L/25) µm
  • XY Repeatability < 7.0 µm
  • Z Repeatability < 5.0 µm

Wenzel CMM

Micro-Vu Precision
Video Measurement System

Romer Absolute Arm 7530
6-axis high accuracy arm
